Product
Product feature.
1 High Comfort Low profile make patient more comfortable.
2 Rigorous Size CNC slot ensure precision and less friction.
3 Ample Space , Ample area under tie-wingfor easy ligation.
4 Tight Fit Contoured base adapt the tooth perfectly.
| Product Parameters (MBT) | |||||||||||
| MBT | Maxillary | ||||||||||
| Tooth | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 | |
| Torque | -7° | -7° | -7° | +10° | +17° | +17° | +10° | -7° | -7° | -7° | |
| Tip | 0° | 0° | +8° | +8° | +4° | +4° | +8° | +8° | 0° | 0° | |
| In/out mm | 0.74 | 0.74 | 0.57 | 0.9 | 0.67 | 0.67 | 0.9 | 0.57 | 0.74 | 0.74 | |
| Width mm | 2.9 | 2.9 | 3.0 | 2.7 | 3.4 | 3.4 | 2.7 | 3.0 | 2.9 | 2.9 | |
| 0.022" no hook | BQM2-2015 | BQM2-2014 | BQM2-2013 | BQM2-2012 | BQM2-2011 | BQM2-2021 | BQM2-2022 | BQM2-2023 | BQM2-2024 | BQM2-2025 | |
| 0.022" with hook | BQM2-2115 | BQM2-2114 | BQM2-2113 | / | / | / | / | BQM2-2123 | BQM2-2124 | BQM2-2125 | |
| 0.018" no hook | BQM1-2015 | BQM1-2014 | BQM1-2013 | BQM1-2012 | BQM1-2011 | BQM1-2021 | BQM1-2022 | BQM1-2023 | BQM1-2024 | BQM1-2025 | |
| 0.018" with hook | BQM1-2115 | BQM1-2114 | BQM1-2113 | / | / | / | / | BQM1-2123 | BQM1-2124 | BQM1-2125 | |
| Mandibular | |||||||||||
| Tooth | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| Torque | -17° | -12° | -6° | -6° | -6° | -6° | -6° | -6° | -12° | -17° | |
| Tip | +2° | +2° | +3° | 0° | 0° | 0° | 0° | +3° | +2° | +2° | |
| In/out mm | 0.9 | 0.76 | 0.51 | 1.14 | 1.14 | 1.14 | 1.14 | 0.51 | 0.76 | 0.9 | |
| Width mm | 2.9 | 2.9 | 3.0 | 2.4 | 2.4 | 2.4 | 2.4 | 3.0 | 2.9 | 2.9 | |
| 0.022" no hook | BQM2-2045 | BQM2-2044 | BQM2-2043 | BQM2-2042 | BQM2-2041 | BQM2-2031 | BQM2-2032 | BQM2-2033 | BQM2-2035 | BQM2-2035 | |
| 0.022" with hook | BQM2-2145 | BQM2-2144 | BQM2-2143 | / | / | / | / | BQM2-2133 | BQM2-2134 | BQM2-2135 | |
| 0.018" no hook | BQM1-2045 | BQM1-2044 | BQM1-2043 | BQM1-2042 | BQM1-2041 | BQM1-2031 | BQM1-2032 | BQM1-2033 | BQM1-2035 | BQM1-2035 | |
| 0.018" with hook | BQM1-2145 | BQM1-2144 | BQM1-2143 | / | / | / | / | BQM1-2133 | BQM1-2134 | BQM1-2135 | |
| Product parameters（Roth） | |||||||||||
| Roth | Maxillary | ||||||||||
| Tooth | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 | |
| Torque | -7° | -7° | -3° | +7° | +12° | +12° | +7° | -3° | -7° | -7° | |
| Tip | 0° | 0° | +13° | +9° | +5° | +5° | +9° | +13° | 0° | 0° | |
| In/out mm | 0.74 | 0.74 | 0.55 | 0.89 | 0.67 | 0.67 | 0.89 | 0.55 | 0.74 | 0.74 | |
| Width mm | 2.9 | 2.9 | 3.0 | 2.7 | 3.4 | 3.4 | 2.7 | 3.0 | 2.9 | 2.9 | |
| 0.022" no hook | BQR2-2015 | BQR2-2014 | BQR2-2013 | BQR2-2012 | BQR2-2011 | BQR2-2021 | BQR2-2022 | BQR2-2023 | BQR2-2024 | BQR2-2025 | |
| 0.022" with hook | BQR2-2115 | BQR2-2114 | BQR2-2113 | / | / | / | / | BQR2-2123 | BQR2-2124 | BQR2-2125 | |
| 0.018" no hook | BQR1-2015 | BQR1-2014 | BQR1-2013 | BQR1-2012 | BQR1-2011 | BQR1-2021 | BQR1-2022 | BQR1-2023 | BQR1-2024 | BQR1-2025 | |
| 0.018" with hook | BQR1-2115 | BQR1-2114 | BQR1-2113 | / | / | / | / | BQR1-2123 | BQR1-2124 | BQR1-2125 | |
| Mandibular | |||||||||||
| Tooth | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| Torque | -22° | -17° | -7° | -1° | -1° | -1° | -1° | -7° | -17° | -22° | |
| Tip | +0° | 0° | +6° | 0° | 0° | 0° | 0° | +6° | 0° | +0° | |
| In/out mm | 0.88 | 0.77 | 0.51 | 1.14 | 1.14 | 1.14 | 1.14 | 0.51 | 0.77 | 0.88 | |
| Width mm | 2.9 | 2.9 | 3.0 | 2.4 | 2.4 | 2.4 | 2.4 | 3.0 | 2.9 | 2.9 | |
| 0.022" no hook | BQR2-2045 | BQR2-2044 | BQR2-2043 | BQR2-2042 | BQR2-2041 | BQR2-2031 | BQR2-2032 | BQR2-2033 | BQR2-2035 | BQR2-2035 | |
| 0.022" with hook | BQR2-2145 | BQR2-2144 | BQR2-2143 | / | / | / | / | BQR2-2133 | BQR2-2134 | BQR2-2135 | |
| 0.018" no hook | BQR1-2045 | BQR1-2044 | BQR1-2043 | BQR1-2042 | BQR1-2041 | BQR1-2031 | BQR1-2032 | BQR1-2033 | BQR1-2035 | BQR1-2035 | |
| 0.018" with hook | BQR1-2145 | BQR1-2144 | BQR1-2143 | / | / | / | / | BQR1-2133 | BQR1-2134 | BQR1-2135 | |
| Product parameters (Edge-wise) | |||||||||||
| Edge-wise | Maxillary | ||||||||||
| Tooth | 15 | 14 | 13 | 12 | 11 | 21 | 22 | 23 | 24 | 25 | |
| Torque | 0° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | |
| Tip | 0° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | |
| In/out mm | 0.6 | 0.6 | 0.6 | 0.65 | 0.65 | 0.65 | 0.65 | 0.6 | 0.6 | 0.6 | |
| Width mm | 3.0 | 3.0 | 3.0 | 2.7 | 3.4 | 3.4 | 2.7 | 3.0 | 3.0 | 3.0 | |
| 0.022" no hook | BQE2-2015 | BQE2-2014 | BQE2-2013 | BQE2-2012 | BQE2-2011 | BQE2-2021 | BQE2-2022 | BQE2-2023 | BQE2-2024 | BQE2-2025 | |
| 0.022" with hook | BQE2-2115 | BQE2-2114 | BQE2-2113 | / | / | / | / | BQE2-2123 | BQE2-2124 | BQE2-2125 | |
| 0.018" no hook | BQE1-2015 | BQE1-2014 | BQE1-2013 | BQE1-2012 | BQE1-2011 | BQE1-2021 | BQE1-2022 | BQE1-2023 | BQE1-2024 | BQE1-2025 | |
| 0.018" with hook | BQE1-2115 | BQE1-2114 | BQE1-2113 | / | / | / | / | BQE1-2123 | BQE1-2124 | BQE1-2125 | |
| Mandibular | |||||||||||
| Tooth | 45 | 44 | 43 | 42 | 41 | 31 | 32 | 33 | 34 | 35 | |
| Torque | 0° | 0° | -7° | 0° | 0° | 0° | 0° | 0° | 0° | 0° | |
| Tip | 0° | 0° | +6° | 0° | 0° | 0° | 0° | 0° | 0° | +0° | |
| In/out mm | 0.6 | 0.6 | 0.6 | 0.65 | 0.65 | 0.65 | 0.65 | 0.6 | 0.6 | 0.6 | |
| Width mm | 3.0 | 3.0 | 3.0 | 3.0 | 2.4 | 2.4 | 2.4 | 3.0 | 3.0 | 3.0 | |
| 0.022" no hook | BQE2-2045 | BQE2-2044 | BQE2-2043 | BQE2-2042 | BQE2-2041 | BQE2-2031 | BQE2-2032 | BQE2-2033 | BQE2-2035 | BQE2-2035 | |
| 0.022" with hook | BQE2-2145 | BQE2-2144 | BQE2-2143 | / | / | / | / | BQE2-2133 | BQE2-2134 | BQE2-2135 | |
| 0.018" no hook | BQE1-2045 | BQE1-2044 | BQE1-2043 | BQE1-2042 | BQE1-2041 | BQE1-2031 | BQE1-2032 | BQE1-2033 | BQE1-2035 | BQE1-2035 | |
| 0.018" with hook | BQE1-2145 | BQE1-2144 | BQE1-2143 | / | / | / | / | BQE1-2133 | BQE1-2134 | BQE1-2135 | |
| Product Code (MBT) | |||
| MBT Bracket (Micro-etched base)Set:5-5 | Set Code | 0.022" | 0.018" |
| 345 with hooks | BQM2-2401 | BQM1-2401 | |
| 3 with hooks | BQM2-2301 | BQM1-2301 | |
| no hook | BQM2-2001 | BQM1-2001 | |
| Product Code (Roth) | |||
| Roth Bracket Set:5-5 | Set Code | 0.022" | 0.018" |
| 345 with hooks | BQR2-2401 | BQR1-2401 | |
| 3 with hooks | BQR2-2301 | BQR1-2301 | |
| no hook | BQR2-2001 | BQR1-2001 | |
| Product Code (Edge-wise) | |||
| Edge-wise Bracket Set:5-5 | Set Code | 0.022" | 0.018" |
| 345 with hooks | BQE2-2401 | BQE1-2401 | |
| 3 with hooks | BQE2-2301 | BQE1-2301 | |
| no hook | BQE2-2001 | BQE1-2001 | |
